KOHLER K-104B87-SANA-CP OBLO 13 7/8 INCH TALL TOUCHLESS FAUCET WITH KINESIS SENSOR TECHNOLOGY AND TEMPERATURE MIXER
The Kohler Oblo touchless faucet combines a bold, design-forward aesthetic with advanced Kinesis sensor technology, making it a sophisticated choice for modern commercial bathroom spaces. Featuring a concealed sensor within the spout, this faucet provides extraordinarily accurate and reliable actuation while maintaining a clean, minimalist profile. The below-counter valving design reduces the faucet's footprint on the deck and simplifies maintenance for high-traffic environments. Engineered for efficiency, it delivers a water-saving 0.5 gpm flow rate and is powered by four AA batteries with a lifespan of up to four years. This complete kit includes a mechanical mixing valve and a grid drain, ensuring a seamless installation and consistent performance.
Features
- Kinesis technology with concealed sensor allows for a clean aesthetic and provides extraordinarily accurate and reliable actuation in varying installation environments
- Below-counter valving reduces the faucet footprint and provides easier service
- Design-forward aesthetic optimized for commercial bathroom spaces
- On-demand usage with 30-second maximum continual run cycle to prevent vandalism and save water
- Vandal-resistant aerator for enhanced durability in public settings
- AA battery-powered operation with up to four-year battery life (approximately 105,000 cycles)
- Single-hole mounting for a streamlined deck appearance
- Includes spout assembly, bathroom sink grid drain with overflow, control box assembly, and mechanical mixing valve
- 18 inch stainless steel braided flexible supply hose for easy installation
Required and Optional Accessories (sold separately)
The following items are NOT included with this product and must be purchased separately.
- Optional (sold separately): Drain treatment K-23726
- Optional (sold separately): 4 inch escutcheon plate for Insight and Kinesis faucet K-13478-A
- Optional (sold separately): 4 inch escutcheon plate for Insight and Kinesis faucet K-13478-B
- Optional (sold separately): 8 inch escutcheon plate for Insight and Kinesis faucet K-13479-A
- Optional (sold separately): 8 inch escutcheon plate for Insight and Kinesis faucet K-13479-B
Specifications
- Material: Brass spout and cast brass valve
- Finish: Polished Chrome
- Installation Type: Single-hole deck mount
- Power Source: Four AA batteries (included)
- Technology: Kinesis sensor technology
- Valve Type: Cast brass with below-counter valving
Dimensions
- Overall Height: 13-7/8 inches
- Spout Reach: 5-3/16 inches
- Spout Height: 11-7/16 inches
- Supply Hose Length: 18 inches
- Sensor Cable Length: 34-7/16 inches
- Tube Length: 47-1/4 inches
- Max Deck Thickness: 1-3/4 inches
- Required Mounting Hole Diameter: 1-1/4 inches minimum to 1-1/2 inches maximum
- Flow Rate: 0.5 gpm (1.9 lpm)
Codes and Standards
- ASME A112.18.1/CSA B125.1
- NSF/ANSI/CAN 61 and NSF/ANSI/CAN 372
- DOE - Energy Policy Act 1992
- California Energy Commission (CEC)
- ADA and ICC/ANSI A117.1 compliant
- CSA B651 and OBC compliant
- Complies with the Safe Drinking Water Act (SDWA)
- KOHLER One-Year Limited Warranty
Why choose the Kohler K-104B87-SANA Touchless Faucet?
- The concealed Kinesis sensor offers a design-forward aesthetic that eliminates bulky external sensors while providing industry-leading response times.
- Battery-powered operation with a 105,000-cycle life ensures long-term reliability and low maintenance in busy commercial restrooms.
- Sustainability is built-in with a 0.5 gpm flow rate and an automatic 30-second shut-off to prevent water waste and vandalism.
- The included mechanical mixer and grid drain provide a comprehensive solution for professional installations requiring precise temperature control.
