Kohler K-104S36-SATA-CP Strayt 5 1/2 Inch Single Hole Deck Mounted Lavatory Bathroom Faucet with Kinesis Sensor Technology in Polished Chrome
The Kohler Strayt touchless lavatory faucet combines bold, contemporary lines with advanced Kinesis sensor technology to deliver a high-performance solution for both residential and commercial environments. Designed with a concealed sensor inside the spout, this faucet provides a clean aesthetic while ensuring exceptionally accurate and reliable actuation across various installation settings. The DC-powered system is engineered for efficiency, featuring a vandal-resistant outlet with a 0.35 gpm flow rate to maximize water savings. Its below-counter valving design reduces the overall footprint on the deck and simplifies maintenance for long-term reliability. Constructed from premium materials and finished in Polished Chrome, this single-hole faucet brings a sophisticated, design-forward look to any modern bathroom.
Features
- Kinesis technology with concealed sensor allows for a clean aesthetic and provides extraordinarily accurate and reliable actuation
- Below-counter valving reduces the faucet footprint and provides easier service
- On-demand usage with 30-second maximum continual run cycle to prevent vandalism and save water
- AA battery-powered system with up to a four-year battery life (approximately 105,000 cycles)
- Stainless steel braided flexible supply hose for easy installation
- Vandal-resistant outlet for enhanced durability in high-traffic areas
- Includes spout assembly, grid drain, control box assembly, supply hose, four AA batteries, and standard mounting hardware
Required and Optional Accessories (sold separately)
The following items are NOT included with this product and must be purchased separately.
- Optional (sold separately): Drain treatment K-23726
- Optional (sold separately): 4 inch escutcheon plate for Insight and Kinesis faucet K-13478-A
- Optional (sold separately): 4 inch escutcheon plate for Insight and Kinesis faucet K-13478-B
- Optional (sold separately): 8 inch escutcheon plate for Insight and Kinesis faucet K-13479-A
- Optional (sold separately): 8 inch escutcheon plate for Insight and Kinesis faucet K-13479-B
- Optional (sold separately): Mechanical mixing valve K-24154
Specifications
- Installation Type: Deck Mounted, Single Hole
- Material: Metal construction
- Power Source: Battery-DC (included)
- Drain Type: K-7129-A Bathroom sink grid drain with overflow included
- Drain Tailpiece included: Yes
- Finish: Polished Chrome
- Handle Style: Electronic touchless
Dimensions
- Overall Height: 5-1/2 inches
- Spout Height: 4-5/8 inches
- Spout Reach: 5-1/4 inches
- Supply Hose Length: 18 inches
- Maximum Flow Rate: 0.35 gpm (1.3 lpm)
- Maximum Static Fixture Pressure: 125 psi (861.8 kPa)
- Minimum Static Fixture Pressure: 20 psi (137.9 kPa)
Codes and Standards
- ASME A112.18.1/CSA B125.1
- NSF/ANSI/CAN 61
- NSF/ANSI/CAN 372
- DOE - Energy Policy Act 1992
- California Energy Commission (CEC)
- ADA Compliant
- ICC/ANSI A117.1
- CSA B651
- OBC Compliant
- KOHLER One-Year Limited Warranty
Why choose the Kohler K-104S36-SATA-CP Bathroom Faucet with Kinesis technology?
- The Kinesis sensor technology is hidden within the spout, offering a seamless design that eliminates the bulky sensors found on traditional touchless faucets.
- With a 0.35 gpm flow rate and a 30-second auto-shutoff, this faucet is an ideal choice for projects seeking LEED certification or significant water conservation.
- The DC-powered battery system provides up to four years of reliable operation, making it a low-maintenance solution for both busy homes and commercial restrooms.
- The included grid drain and flexible stainless steel supply hoses ensure you have the essential components for a streamlined installation process.
