Kohler K-45345-BA-CP 12 1/8 Inch Single Hole Electronic Bathroom Faucet With Insight Technology with Less Drain Assembly
The Kohler K-45345-BA-CP Gooseneck bathroom faucet represents a breakthrough in commercial and high-end residential plumbing technology. This shelf-back base sink faucet features the Kohler Hybrid Energy System, a first-of-its-kind 30-year power solution that ensures long-term reliability for touchless operation. Integrated Insight adaptive infrared technology provides accurate and consistent sensor activation by tuning into the specific environment. The high-arc gooseneck spout offers ample clearance for handwashing while maintaining a sleek, modern aesthetic. Constructed from durable brass and finished in Polished Chrome, this faucet is designed for heavy-use environments that require water efficiency and vandal resistance.
Features
- Electronic Insight sensor technology for accurate and consistent activation
- Factory-set 30-second maximum continual run cycle to prevent water waste
- Vandal-resistant rosebud spray aerator
- Includes 30-year Hybrid Energy Cell for a virtually maintenance-free power solution
- Waterproof shroud protects electronic components from moisture and damage
- Temperature control handle option for customized user comfort
- Above-counter valve design for easy installation and routine maintenance
- Made in the U.S.A.
Required and Optional Accessories (sold separately)
The following items are NOT included with this product and must be purchased separately.
- Optional (sold separately): Drain treatment K-23726
- Optional (sold separately): Additional aerator styles
Specifications
- Material: Brass
- Finish: Polished Chrome
- Installation Type: Deck-mount, single-hole mounting
- Technology: Insight adaptive infrared technology
- Valve Type: Above-counter valve
- Drain Assembly: Not included (Less drain)
Dimensions
- Overall Height: 12-1/8 inches
- Spout Height: 9 inches
- Spout Reach: 6-3/16 inches
- Supply Hose Length: 24 inches
- Supply Connection: 3/8 inch compression fitting
- Minimum Mounting Hole Diameter: 1-1/4 inches
- Maximum Mounting Hole Diameter: 1-1/2 inches
- Maximum Deck Thickness: 2 inches
- Maximum Basin Lip Height: 3/4 inch
- Minimum Distance from Spout to Wall: 1-3/4 inches
- Maximum Distance from Basin Edge to Spout Base: 1-3/4 inches
- Maximum Flow Rate: 0.35 gpm (1.3 lpm)
Codes and Standards
- ASME A112.18.1/CSA B125.1
- NSF/ANSI/CAN 372
- DOE - Energy Policy Act 1992
- ADA Compliant
- ICC/ANSI A117.1
- CSA B651
- OBC Compliant
- KOHLER One-Year Limited Warranty
Why choose the Kohler K-45345-BA-CP Bathroom Faucet 0.35 gpm flow rate?
- The ultra-low 0.35 gpm flow rate provides exceptional water savings, making it an ideal choice for LEED-certified buildings and eco-conscious facilities.
- Insight technology uses an adaptive infrared sensor that minimizes false triggers, ensuring the faucet only runs when hands are actually present.
- The 30-year Hybrid Energy Cell eliminates the need for frequent battery changes, significantly reducing maintenance costs over the lifetime of the fixture.
- Its vandal-resistant components and durable brass construction are engineered to withstand the rigors of high-traffic commercial restrooms while maintaining a polished appearance.
