Elkay LRAD1316601 Stainless Steel 13 L x 16 W x 6 D Top Mount Kitchen Sink, 1 Faucet Hole
The Elkay Lustertone Classic stainless steel sink offers a timeless look that complements both traditional and modern kitchen designs. This single bowl drop-in sink is meticulously crafted from high quality 18 gauge 304 stainless steel, ensuring long lasting durability and resistance to daily wear. Designed with accessibility in mind, it features a 6 inch depth that meets ADA compliance standards when installed correctly. The lustrous satin finish provides a professional appearance while being easy to clean and maintain. Integrated sound deadening pads on the bottom of the bowl minimize noise and vibration for a quieter experience at the sink. This compact 13 inch by 16 inch sink is an ideal solution for smaller kitchens, bar areas, or utility spaces requiring a high performance workspace.
Features
- Manufactured from 18 gauge 304 stainless steel for superior strength and durability.
- Lustrous satin finish provides a reflective, professional look that is easy to maintain.
- Bottom-only sound deadening pads reduce noise from splashing water and clattering dishes.
- U-channel installation system allows for a streamlined drop-in mounting process.
- Center drain placement provides a symmetrical look and efficient drainage.
- ADA compliant design provides the necessary clearance for accessible installations.
Required and Optional Accessories (sold separately)
The following items are NOT included with this product and must be purchased separately.
- Optional (sold separately): Deluxe 3-1/2" Drain Type 304 Stainless Steel Body Strainer Basket Rubber Seal and Tailpiece LK99
- Optional (sold separately): 3-1/2" Drain Fitting Stainless Steel Body Strainer Basket and Offset Tailpiece LKAD35
- Optional (sold separately): Elkay Gourmet Single Hole Bar Faucet Pull-out Spray and Lever Handle LKGT1042
- Optional (sold separately): Installation hardware LK364
- Optional (sold separately): Installation hardware LK463
Specifications
- Material: 304 Stainless Steel
- Finish: Lustrous Satin
- Gauge: 18
- Installation Type: Drop-in (Top Mount)
- Number of Bowls: 1
- Minimum Cabinet Size: 18 inches
- Drain Placement: Center
- Mounting Hardware: Part 64090010 included for countertops up to 3/4 inch (19mm) thick
- Number of Faucet Holes: 1
Dimensions
- Sink Dimensions: 13 inches x 16 inches x 6 inches
- Bowl 1 Dimensions: 10 inches x 10 inches x 5-7/8 inches
- Drain Size: 3-1/2 inches (89mm)
- Cutout Dimensions: 12-3/8 inches x 15-3/8 inches (314mm x 391mm)
- Corner Radius: 1-1/2 inches (38mm)
Codes and Standards
- ADA and ICC A117.1
- ASME A112.19.3/CSA B45.4
- IAPMO Listed (Uniform Plumbing Code, International Plumbing Code, National Plumbing Code of Canada)
- Limited Lifetime Warranty
Why choose the Elkay LRAD1316601 Kitchen Sink 18 gauge stainless steel?
- The 18 gauge 304 stainless steel construction provides a heavy duty foundation that resists corrosion and stands up to heavy use in residential or commercial settings.
- A 6 inch bowl depth ensures the sink is accessible and comfortable for all users while maintaining functionality for various kitchen tasks.
- The Lustrous Satin finish is specifically designed to mask small scratches that occur over time, keeping your sink looking newer for longer with minimal effort.
- The versatile drop-in design allows for easy installation into existing countertops, making it a perfect choice for quick upgrades or complete renovations.
