Sloan 3370400 ECOS 8111 Dual-Flush Exposed Sensor Water Closet Flushometer, Battery, 1.6 or 1.1 GPF, 1 Inch IPS Inlet, 1 1/2 Inch Spud, 15 to 80 PSI, Polished Chrome
Similar Products
Product details
UPC | 00671254341661 | ||
Flush Type | Electronic / Toilet | ||
Spud Placement | Top | ||
Finish | Chromes | ||
Material | Brass | ||
Spud Connection Size | 1.5 | ||
Collection | ECOS | ||
|
Sloan 3370400 ECOS 8111 Dual-Flush Exposed Sensor Water Closet Flushometer, Battery, 1.6 or 1.1 GPF, 1 Inch IPS Inlet, 1 1/2 Inch Spud, 15 to 80 PSI, Polished Chrome
Sloan ECOS Sensor Exposed Flushometer, Dual-Flush, Series: 8111, Water Closet Fixture, Battery, 1.6/1.1 gpf Flush, 1 in IPS Inlet, 1-1/2 in Spud Coupling, 11-1/2 in Rough-In, Diaphragm, Connection Location: Top Spud, 22 to 42 in Sensor, 15 to 80 psi, Semi-Red brass, Polished Chrome.
Features:
- If the user is present for less than one minute and leaves the sensing zone or chooses the small override button a reduced flush initiates (1.1 gpf/4.2 Lpf) eliminating liquid and paper waste saving 1/2 gallon of water
- If the user is present for greater than one minute and leaves the zone or chooses the large override button the full flush initiates (1.6 gpf/ 6.0 Lpf) eliminating solid waste and paper
- Reduces water volume by up to 30% when a reduced flush occurs
- PERMEX synthetic rubber flex tube diaphragm with twin linear filtered by-pass and vortex cleansing action designed for improved life and reduced maintenance
- ADA compliant Sloan ECOS electronic dual flush battery powered infrared sensor for automatic no hands operation
- Infrared sensor with multiple-focused lobular sensing fields for high and low target detection with range adjustment screw
- Latching solenoid operator
- Engineered metal cover with replaceable lens window
- User friendly three sec auto flush delay
- Courtesy Flush override button
- Four (4) size AA alkaline batteries included
- Duracell with duralock power preserve technology-guaranteed for up to 10 years in storage
- Low battery flashing LED
- Initial set-up range indicator light (first 10 minutes)
- 1 in IPS screwdriver Bak-Chek angle stop
- Free spinning vandal-resistant stop cap
- Adjustable tailpiece
- High back pressure vacuum breaker flush connection with one-piece bottom hex coupling nut
- Spud coupling and flange for 1-1/2 in top spud
- Top sensor position
Specifications:
- Pressure Rating: 15 to 100 psi
- Series: 8111
- Type: Dual Flush
- Material: Semi-Red brass
